Wood thermo fireplace
Widro 85 Evo
kW
OPEN EXPANSION TANK
• combustion chamber white Ecokeram
• smoke outlet Ø 20 cm upper, female
• tilt and ups & downs door opening for the glass cleaning
• fixed or removable handle
• thick steel structure
• Manual flue gas bypass valve with Starter function
• post-combustion system
• Configured for rotisserie function
• 4 Pivoting wheels easing handling while fitting
Optional:
• Frame
• Hood mounting template
• Roasting spit
• Hydraulic kits
| Technical data | min/max | |
| width | cm | 103 |
| depth | cm | 72,5 |
| height | cm | 165 |
| fireplace mouth measurement (W x D x H) | cm | 77x48x45 |
| useful output | kW | 28 |
| useful output to the water | kW | |
| efficiency | % | 86,6 |
| fuel consumption | kg/h | 7 |
| water content | l | 115 |
| Ø combustion product outlet | cm | 20 |
| total weight | kg | 561 |
| vol. that can be heated (depending on the type of system) | m³ | 730 |
