Blade2 H 18 Up
Blade2 H 22 Up
steel
23 kW
Pellet thermo stove
Blade2 H 18 Up
Blade2 H 22 Up
steel
Space-saving pellet boiler stoves - a mere 39 cm in width and available with two power levels. They produce hot water to power radiators and radiant floor panels; they heat the room with adjustable front hot air ventilation that can also be deactivated.
• Steel combustion chamber
• Ceramic ignitor
• Smoke outlet Ø 8 cm upper
• Daily/weekly program
• Hot air ventilation (modulable and deactivatable)
• Synoptic panel on top
• Pellet level sensor
• THE MIND system with built-in wi-Fi
• Leonardo system
• Closed expansion tank included
AVAILABLE MODELS:
• bordeaux steel
• black steel
• opaque white steel
• bronze steel
OPTIONAL
• Kit smoke outlet rear or left side
• Hydraulic kits
• Anti-condensation valve
| Technical data |
Blade2 H 18 Up min/max |
Blade2 H 22 Up min/max |
|
| width | cm | 104 | 104 |
| depth | cm | 39 | 39 |
| height | cm | 120,5 | 120,5 |
| useful output | kW | 5,4/19,2 | 5,4/22,8 |
| useful output to the water | kW | 15,5 | 19 |
| efficiency | % | 91,7 | 91,6 |
| fuel consumption | kg/h | 1,2/4,4 | 1,2/5,2 |
| tank capacity | kg | 30 | 30 |
| autonomy | h | 7/25 | 6/25 |
| water content | l | 20 | 20 |
| Ø combustion product outlet | cm | 8 | 8 |
| Ø external air intake | cm | 5 | 5 |
| total weight | kg | 259 | 259 |
| vol. that can be heated (depending on the type of system) | m³ | 500 | 595 |
